Hobart AMXR‐HL Hood Type Dishwasher with Auto Hood Lift / 134kg / D815xW711xH1510 mm / 1Y Warranty
- Hood-type dishwasher for straight through or corner operation
- Integrated drain heat recovery
- Nominal capacity up to 60 racks/h or 1,080 plates/h or 2,160 glasses/h
- 6 automatic cycles: short, standard, intensive, starch-removal, permanent, hygiene
- Heat and noise insulated hood
- Strainer soil sensor
- Refill signal (detergent / rinse aid)
- Self-cleaning program
- USB-interface for comfortable download of operational data
- Ready to install - completely equipped: fill / drain hose, electrical cable, detergent dispenser, rinse aid dispenser, rinse pump, drain pump and back-flow preventer
- Tank, frame, wash / rinse arms and panels are stainless steel 1.4301
- 1 plate rack P-18-12
- 1 universal flat rack B-00-07
- 1 plastic cutlery rack CB8
Variants
| Order number |
Description |
| AMXR |
Basic model 415 / 50 / 3NPE - 15 amp. Cold water connection
|
| AMXR-V |
AMXR with an addition of VAPOSTOP - prevents steam escaping from the machine when the hood is opened
|
| AMXR-HL |
AMXR with AUTO HOOD LIFT - closes hood at a push of a button & opens automatically at the end of a cycle. Loading height 440 mm. Back panel is included
|
| AMXR-VHL |
AMXR with VAPOSTOP and AUTO HOOD LIFT
|
- VISIOTRONIC-TOUCH control: colour touchscreen (displays text and graphic) in conjunction with single-button control and remaining cycle time indication
- WASHSMART app: controlling your warewash operation with smart technology: status and messages, usage and operating costs, hygiene, service and consumables order
- Drain heat recovery transfers heat from hot drain water to the fresh-water supply, reducing boiler power consumption and saving up to 36% of costs
- SENSO-ACTIVE resource management: constantly measures the quality of the wash water and keeps the amount of rinsing needed in each rinse cycle to the minimum in order to guarantee a fully hygienic wash result
- Exhaust energy storage: the fully enclosed 4-sided hood keeps steam and energy inside the system: energy saving up to 3 kW, less humidity in the kitchen area and better hygienic conditions
- CLIP-IN wash and rinse arms: wash and rinse arms can be removed with one hand and without any tools
- GENIUS-X² fine filter system: advanced filter system with pre-wash function reduces detergent consumption up to 35 %
- VAPOSTOP (optional): prevents vapour escapingfrom the machine when the hood is opened
- Interlocked strainer: prevents operation without tank strainer
- EASY-CLEAN concept: blue markings in the machine help the operator to identify the components which require cleaning
- Watermark approved toWMTS-101:2018, Cert. WMKT21944
Technical data
| Cycle Times* |
60 / 90 / 180 / Continuous (20mins) |
| Water Consumption |
2 l/rack |
| Tank Capacity |
23 l |
| Tank Heating |
2.5 kW |
| Power Supply |
415 / 50 / 3NPE |
| Booster Loading - Standard |
6.2 kW |
| Total Loading - Standard |
7.1 kW l 3 x 15 A |
| Wash Pump |
0.7 kW |
| Rack Size |
500 x 500 mm |
| Loading Height |
440 mm |
| Noise Level |
66 dB (A) |
| Weight (gross / net) |
134 / 114 kg |
Accessories
| Order number |
Description |
| SEF-15/054 |
Back panel (required if unit is not installed against wall, all units have closing frame to wall at rear)
|
| SEF-14/043 |
Thermolabel temperature setting.
|
